3314D UPS Test Loads
(Call for price and delivery information)

3314D Series DC Electronic Load ( Plug-in Dynamic Load Module )

3314D series Module are used with the 3302C single mainframe and 3300C 4ch Mainframes.
Each 3314D Series Module has its own control and display panel, CC/CR/CV/CP/Dynamic modes, 150 Store/Recall memory which provides load set-up more efficiently.
SHORT time setting and SHORT_VH, SHORT_VL setting function
Dynamic can be simulated under CC, CP mode. The current Rise/Fall slew rate can be adjusted individually and there is and external signal input so that load can have a simulated Arbitrary Waveform.
OCP, OPP test function operated by both mainframe and module that will be more effective and accuracy on OCP, OPP testing.
Programmable Load ON/OFF voltage, GO/NG meter check, Voltage meter display "+" or "-" is selectable and 150 sets larger memory is much advance features than 3314C series.

(This Product is a Special Order item and can be purchased by Telephone Order Please call (408)924-0800 for further details.)

Part# 3314D

Click here for detailed specifications.
